Zephyr Essentials Power Cyclone 30" White Under Cabinet Hood

Zephyr

Model #:

AK6500W

Model #: AK6500W
12327
Zephyr
$369.00

At a Glance

Product Dimensions 7.69"h x 30"w x 22.31"d

Zephyr Essentials Power Cyclone 30" White Under Cabinet Hood with incandescent lights and 650 CFM fan speedRead More

$369.00

What We Offer

Protect Your Purchase
None Selected
Services
None Selected
You Might Also Need
None Selected

Get to know this product.

Product Overview

Product Overview

    650 CFM Fan Speed

    Maximum 5 Sones Noise Level

    Self Cleaning

    Removable Clean Cups and Safety Grills

    Dishwasher Safe Accessories

    Fully Concealed Underside

    Incandescent Lights and Mechanical Slider Controls with 3 Speed Levels

    3-Way Ducting



Useful Documents
Product Manual
Specification Sheet
Specifications

General Specs

Width (in.)30
Height (in.)7.69
Duct Size (in.)6
Depth (in.)22.31
ColorWhite
PositioningStationary
Manufacturer Warranty1 Year Labor / 10 Year Parts
Color Finish NameWhite
Appliance Fit Width (in.)30
Product Weight (lbs.)90
Maximum CFM650
Voltage120
Frequency60

Construction

Exhaust:External vented
Chimney:Fixed
Ductwork Type:3.25 x 10

Dimensions

Shipping Weight:98
Depth, Chimney :3.25
Min Chimney Height:16.38
Max Height Above Cooktop:36
Min Height Above Cooktop:26

Display

Controls:Mechanical

General Features

Filter Type:Dishwasher Safe Clean Cups
Cleanability:Smooth surface easy cleaning
Pollutant Removal:Dishwasher Safe Filters

Other

Watts:40
Considerations:If available, also refer range manufacture''s height clearance requirements and recommended hood mounting height above range.
Number of Lights:2
Settings:3
Air Mover Type(s):Internal Blower
Air Mover(s) Speed:650
Number of Air Movers:1
Sones (Noise Level) Rating:5

Styling

Design:Modern
